The top-rated dialysis meter for quick and accurate measurement of conductivity, temperature, and pH.

The pHoenix XL digital dialysate meter is a convenient, hand-held, syringe-style meter for quick and accurate measurement of conductivity, temperature, and pH. Its compact size is easy to use and stores easily when not in use.

  • Verification of three crucial treatment parameters (Conductivity, pH and Temperature) helps to ensure safe, optimal dialysis therapy for your patients
  • Auto-ranging feature automatically selects the proper conductivity range for measurement of various solutions
  • Intuitive onscreen menus and calibration process
  • Expanded measurement ranges and enhanced resolution for temperature, pH and conductivity
  • Eliminates the need for pH paper
Phoenix XL Replacement Module for Dialysis Meter
Dialysis Solution

Better User Experience

  • Ambidextrous design accommodates all users
  • Push-button calibration is fast and easy
  • Three instant readings in one easy step saves valuable time
  • Hold feature freezes readings on the digital display for easy recording
  • Ergonomic handle offers safe and comfortable operation

Reduced Cost Of Ownership

  • Replacement module eliminates need to send in your meter for service
  • Extended Battery Life with new, 6V Lithium Battery (PN 210427-001)
  • Replaces RO water meter with extended measurement range
  • Can calibrate multiple points at once using Mesa’s 0 mS/cm - 7.0pH combo solution (PN 02.0070)
  • Splash-resistant, rugged design protects the meter from falls and spills

Never Be Without Your Meter Again!

Instead of sending your meter in every year for calibration, Mesa has engineered the pHoenix XL to offer a replacement measurement module that can be easily replaced in the field. Simply order a new, calibrated replacement module, replace, and you are all set!

FDA Quality Assurance Guidelines recommend that the conductivity, pH and temperature of the final dialysate are checked with an independent reference meter before every treatment. These readings should be documented on the patient’s daily dialysis record.



Technical Specifications


Range
Resolution
Accuracy
Conductivity
Temperature compensation:
15 to 45˚C
120 to 200 mS/cm
80 to 119 mS/cm
20 to 80 mS/cm
2.0 to 20.0 mS/cm
100 μS/cm to 2.00 mS/cm
5 to 99 μS/cm
1 mS/cm
1 mS/cm
1 mS/cm
0.1 mS/cm
10 μS/cm
1 μS/cm
±5 mS/cm
±2 mS/cm
±1mS/cm
±0.1 mS/cm
±10 μS/cm
±5 μS/cm
Temperature
15.0 to 90.0˚C 0.1˚C ±0.5˚C
PH
2.0 to 12.0 pH units 0.1 pH unit ±0.1 pH unit



Physical Specifications

Dimensions
Weight
Power
Battery Type
H 11.0” x W 2.875” x D1.625” (28 x 7.3 x 4.1 cm)
8.8 oz (249 g) Battery
3.6V Lithium (P/N 210427-001)



Ordering Guide

  Catalog # Description Includes
  36-00300
pHoenix XL METER
1 pHoenix XL Meter with control syringe, Sample tube, Dialysis ma- chine sample port adapters, Calibration labels
  36-00180
pHoenix XL PACKAGE
1 pHoenix XL Meter, NEO-CARE Cell Cleaning Solution (16 oz), 4.0 and 10.0 pH Buffer Solutions (16 oz), 1 mS and 100 mS Standards Solutions (16 oz), 14.0 mS/cm - 7.0 pH Combination Solution (2 bottles, 16 oz)
  36-00175
pHoenix XL SYSTEM
3 pHoenix XL Meters, NEO-CARE Cell Cleaning Solution (16 oz), 4.0 and 10.0 pH Buffer Solutions (16 oz), 1 mS and 100 mS Standards Solutions (16 oz), 14 mS/7 pH Combination Solution (2 bottles, 16 oz), Cal-Station (4 bottle unit)
  36-00185
pHoenix XL SUPER SYSTEM
3 pHoenix XL Meters, NEO-CARE Cell Cleaning Solution (16 oz), 4.0 and 10.0 pH Buffer Solutions (16 oz), 1 mS and 100 mS Standards Solutions (16 oz), 14 mS/7 pH Combination Solution (2 bottles, 16 oz), Super Station (9 bottle unit)
Phoenix XL
SOLUTION
P/N 36-00310
pHoenix XL Replacement
Measurement Module
P/N 02.0070 (qt.) 02.0062 (pt.)
14 ms/7 pH Combination
Solution
